      SD7880
      SINGLE STAGE PRIMARY SIDE REGULATION HIGH POWER FACTOR LED DRIVER IC WITH PWM/LINEAR DIMMING

          The SD7880 is a single stage primary side regulation (PSR) high power factor LED driver with dimming function, it has PWM and linear dimming functions, with dimming depth up to 5%, it is mainly used in isolated flyback smart LED lighting system.

          The SD7880 provides accurate constant current control and operates in boundary conduction mode (BCM) with high efficiency. It adopts primary side regulation eliminating the opto-couple, secondary feedback control and loop compensation, which effectively simplifies the design and reduces the system cost.

          The SD7880 provides complete protections such as short LED protection, open LED protection and over temperature protection, etc.



      Main feature

      • Dimmable range of 5% to 100%

      • PSR flyback topology

      • Boundary conduction mode

      • Low start-up current

      • Leading edge blanking

      • VCC over voltage protection

      • VCC under voltage lockout

      • Over temperature protection

      • Short LED protection and Open LED protection


      Ordering Information
      Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
      SD7880 SOP-8-225-1.27 / Halogen free Tube
      SD7880TR SOP-8-225-1.27 / Halogen free Tape & Reel
      Block Diagram


      Documents
      title Types of Size (KB) date Download the latest English version
      SD7880 PDF 338 2023-12-05 SD7880 简要版说明书
